Pitch: 0.4 mm (0.016 in)
Data Rate: 28 Gbps
Application: Power, Signal
Unit Weight: 755.514 mg
Stack Height: 4 mm, 4.5 mm, 5.5 mm
Current Rating: 1.6 A
Mounting Angle: Vertical
Mounting Style: SMD/SMT
Number of Rows: 2 Row
Voltage Rating: 155 VAC
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Maximum Data Rate: 28 Gbps
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 60 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
