- Power modules
Power offering (kW): 60kW (62.5kW optional)
Module qty: 60kW*7
- Frame options
600kW: Standard offer input /output /MBS /bypass swithes
- General characteristics
Efficiency in Energy Saver System (ESS): Up to 99%
Efficiency in double-conversion mode: Up to 97%
Parallel capability: Standard 4 units external parallel (Max 8 units with factory customization)
Cold start: Supported
Softstart: Rectifier ramp up, compatible with generator, ramp up rate configurable
- Input characteristics
Voltage: 380/400/415V
Voltage range: 301~478V L-L
175~276V L-N
Frequency range: 50/60 Hz
Power factor: > 0.99
Input current distortion: < 3% @ 100% load capacity
- Battery
Battery Type: Lithium, VRLA
Charging method: ABM
Battery Voltage: 432-528Vdc (Selectable)
Battery Connection: Two wire ( no neutral )
- Output
Voltage: 380/400/415V 4 wire
Frequency range: 50/60 Hz
Regulation: ±1% steady state
Voltage THD: < 1% (100% linear load)
< 5% (non-linear load)
Overload: 125% 10 mins
- Compliance with standards
Safety: IEC 62040-1
EMC: IEC 62040-2
Performance: IEC 62040-3
RoHS: EU directive 2011/65/EU
