Nominal voltage AC: 320 V / 550 V + 0% / 50 - 60 Hz
Nominal voltage DC: 380 V + 0% (L -> N, PE)
Nominal max. current: 4 x 16 A at 40° C room temperature
Series inductance (BURST): 5 x 120 µH / 16 A
Single choke (SURGE): 4 x 1,5 mH / 16 A
Lamps for phase indication: L1, L2 , L3: green, N: red
Coupling impedances/Burst Coupling: 33 nF
Coupling impedances/Surge coupling: L – PE, N – PE: 9 µF + 10 , L – L, L – N: 18 µF
Coupling Modes: Burst L1, L2, L3, N, PE individually and in any combination against earth
Coupling Modes: Surge L – L, L – N, L – PE, N – PE
Logic signal input: BNC - jack
High voltage input Burst: Fischer high voltage jack D103A023
High voltage input Surge: Fischer high voltage jackD105A039
Connection for test sample supply: laboratory-banana-jacks
Connection for test specimen: laboratory-banana-jacks
Electronics power supply: 100-240 V / 47-63 Hz / 80 VA (power entry module with line filter
on rear side)
Additional ground sockets: on front and rear side
Operating temperature: 0 - 40 °C
Housing: 19" housing, 3 HE
Weight: approx. 20 kg
