Tension Range: 50 – 5000 cN
Resolution: 1 cN
Measuring Head Width*: 116 mm
Applications Textile Industry (e.g Yarn Count): max. 5000 tex
Applications Wire Industry (e.g. soft-annealed Copper Wire): 0.40 – 1.00 mm Ø
SCHMIDT Calibration Material PA**: 0.60 + 1.20 mm Ø
SCHMIDT Calibration Material soft-annealed copper wire***: 0.60 + 1.00 mm Ø
Material-Thickness Compensator: x
Calibration: According SCHMIDT factory procedure
Accuracy:
+ For PA from 5 % up to 100 % full scale: ± 0.5 % full scale, ± 1 digit
+ remaining tension range and other calibration materials: ±3 % full scale and ±1 digit
Memory for material curves: 2 for SCHMIDT calibration plus 9 for customized calibrations
Measuring units:
+ Force (switchable): cN, daN, g, kg, N, lb
+ Thickness (switchable): mm, inch
Overrange: Approx. 10 % full scale, without accuracy guarantee
Overload protection: 100 % full scale
Measuring principle: Strain gauge bridge
Signal processing: Digital, 16 bit A/D converter
Measuring frequency: Max. 1 kHz (1000 measurings/sec), intern 8 kHz
Measuring roller deflection: Max. 0.2 mm
Display: Graph LCD
3 different displays: Numeric, Numeric with graph (time-tension); X-Y-diagram
Display update rate: Approx. 2 times per second
Memory: MIN, MAX, PEAK, AVG and LAST
Output signal: USB
Memory: 60.000 values split up to 255 measuring positions
Memory modes: 5 memory modes with statistical evaluation
Damping: Adjustable electronic damping (averaging)
Cal. Adjustment: ± 10 steps in 1 % increment
Thickness compensation: Max. 2.5 mm (not available for all models)
Auto power off: Approx. 3 minutes of non-use
Temperature coefficient: Gain: less than ± 0.01 % full scale /°C
Zero point: Less than ± 0.03 % FS* /°C
Temperature range: 10 – 45 °C
Air humidity: 85 % RH, max.
Power supply: LiPo accumulator (approx. 40 h continuous use), charging time approx. 3 1/2 h, USB AC adapter 100 – 240 V AC with 4 adapters (EU/USA/UK/AUS-NZ)
Housing material: Die-cast aluminium
Housing dimensions: See Dimensions
Weight, net (gross): approx. 875 g (1550 g)
* Depending on model, either width of filament guide or outer distance between outside guide rollers
** Suitable for 95 % of applications
*** Accuracy: ± 3 % full scale (FS) and ± 1 dgit
Delivery Includes: carrying case, accumulator and USB AC adapter with 4 adapters (EU/USA/UK/AUS-NZ), USB cable, Software Tension Inspect 3, Certificate of compliance with the order 2.1 according EN 10204 free of charge, instruction manual in German or English (as requested)
