SCHMIDT ZF2-50 Tension Meter (5 – 50 cN)

Tension Range: 5 – 50 cN

Measuring Head Width*: 43 mm

SCHMIDT Calibration Material**: PA: 0.12 mm Ø

Calibration: According to SCHMIDT factory procedure

Accuracy: ±1 % full scale or ±1 graduation on scale

Scale diameter: 54 mm

Temperature range: 10 – 45 ºC

Air humidity: 85 % RH, max.

Housing material: Plastic (POM)

Dimensions: See dimensions

Weight, net (gross): Approx. 200 g (600 g)

Other tension ranges available on request.

Other units of measure available, such as g.

*  Width of filament guide

** Suitable for 95 % of applications – PA = Polyamide Monofilament

Delivery Includes: carrying case, operating instruction in German or English (as requested), Certificate of Compliance with the order 2.1 according DIN EN 10204 free of charge
