SCHNEIDER SSL1A12BDR Solid State Relays 2A 24-280VAC RANDOM 15-30VDC SSR SLIM 1
Manufacturer: SCHNEIDER Model: SSL1A12BDR - Contact
Width: 5 mm (0.197 in)
Height: 15 mm (0.591 in)
Length: 28 mm (1.102 in)
Output Type: SCR
Input Current: 6 mA
Mounting Style: Socket Mount
Relay Contact Form: 1 Form A (SPST-NO)
Load Current Rating: 2 A
Load Voltage Rating: 24 VAC to 280 VAC
Control Voltage Range: 15 VDC to 30 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 20 C
