Nominal Frequency Range: 400 MHz…2.8 GHz
Isotropic Gain (Farfield): 8 dBi…18 dBi
Antenna Factor (Farfield): 14…32 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: 2
Standing Wave Ratio SWR max.: 3.5
Front to Back Ratio: typ. > 25 dB
Cross Polarisation: typ. > 25 dB
3 dB Beamwidth typ. (E-Plane): 45°
3 dB Beamwidth typ. (H-Plane): 45°
Max. Input Power: 3 kW @ 400 MHz / 1.5 kW @ 2 GHz
Connector: 7-16 connector female
Center Mount: 3/8", M12
Width × Length × Thickness: 550 × 990 × 460 mm
Weight: 10 kg
Recommended Accessories: AM 9144 Mast
