Frequency range (nominal): 9 kHz – 2 GHz
Noise figure: typ. 2.5 dB (1.0 GHz)
Gain: typ. +30 dB
Amplitude flatness: < ±3 dB
1 dB compression point at input: > –20 dBm (87 dBµV)
Impedance: 50 Ω
VSWR input / output: < 2 : 1
Ambient temperature: –10° … +60°C
Power supply: External +10 – 15 V / 120 mA
Coaxial power connector: 5.5 mm / 2.5 mm
Current consumption: < 120 mA
Material of the housing: Aluminium
Housing dimensions: 42 × 35 × 27 mm
Overall dimensions: 82 × 38 × 27 mm
Weight: 150 g
