Frequency Range (nominal): 9 kHz – 200 MHz
Frequency Range (useable): 9 kHz – 300 MHz
Coaxial Connector (male): N
Power Supply: 5 V DC < 100 mA
Power Supply and Logic Connector: Binder 99-0421-10-07, Series 712
Antenna Factor for fictional E-field strength: 42…70 dB/m
VSWR: typ. < 1.5 (20 kHz – 50 MHz)
Decoupling of the axis: typ. > 20 dB
1 dB Compression at Output: typ. 118 dBµV
Loop Diameter: 112 mm
Dimensions: 550 × 146 × 146 mm
Weight: 850 g
Environmental Conditions: –10 °C to +50 °C, IP54
