Nominal Frequency Range: 7.5...18 GHz
Isotropic Gain: 16 ... 21 dBi i
Antenna Factor: 31 ... 37 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical:1.2
Standing Wave Ratio SWR max.: < 2 (8-18 GHz)
Front to Back Ratio: typ. > 30 dB
Cross Polarisation: typ. > 30 dB
3 dB Beamwidth typ. (E-Plane): 12°-19°
3 dB Beamwidth typ. (H-Plane): 12°-20°
6 dB Beamwidth typ. (E-Plane): 20°-30°
6 dB Beamwidth typ. (H-Plane): 20°-30°
Max. Input Power: 1 kW cont.
Connector: Waveguide flange: WRD750D24
Mount: Waveguide
Width x Length x Thickness: 124 x 241 x 104 mm
Weight: 390 g
