Frequency Range: (9 kHz) 150 kHz – 30 MHz
Impedance (asymm.): 150 Ω ± 20 Ω
Phase (asymm.): 0° ± 20°
Longitudinal Conversion Loss (LCL): acc. CISPR 32 Table C.2
Voltage Division Ratio for asymmetrical voltage: 10 dB ± 1.5 dB
EuT, AT Terminals: 4 mm jacks, equilateral triangle, 19 mm distance
Measuring Port: 50 Ω BNC
Max. Voltage: 400 V AC
Max. Current: 3 A
Insertion Loss (Differential Mode): < 3 dB (100 Ω sym.)
Outer dimensions (H × W × D): 119 × 250 × 105 mm
Weight approx.: 1.5 kg
According to standards: CISPR 16-1-2, CISPR 32, CISPR 15
