Nominal Frequency Range: 200 MHz ... 1.5 GHz
Usable Frequency Range: 150 MHz ... 4 GHz
Isotropic Gain: 9 ... 10 +/- 1 dBi
Antenna Factor: 8 ... 24 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio (SWR) typical: < 1.5
Front to Back Ratio: > 16 dB
Cross Polarisation: > 30 dB (200 MHz ... 1 GHz)
3 dB Beamwidth typ. (E-Plane): 64° - 53°
3 dB Beamwidth typ. (H-Plane): 63° - 44°
Connector (female): 7/16, N
Max. Input Power (7/16): 3 kW (intermittent), 2 kW (continuous)
Max. Input Power (N): 2 kW (intermittent), 1 kW (continuous)
Mount: 22 mm Tube
Width × Length × Height: 930 × 890 × 940 mm
Weight: 4.6 kg
