Nominal Frequency Range: 380 MHz...6 GHz
Usable Frequency Range: 300 MHz ... 8 GHz
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: < 2
Unbalance: < 1.0 dB, typ. < 0.5 dB
Cross Polarisation Rejection: typ. > 20 dB
0…-4 dB Uniform Area Dimension in 10 cm Distance: x ~ 30 cm, y ~ 20 cm
Max. Input Power: 300 W
Isotropic Gain: 2...10 dBi
Antenna Factor: 20...38 dB/m
3 dB Half-Power-Beamwidth E-Plane: typ. 30° … 68°
3 dB Half-Power-Beamwidth H-plane: typ. 40°… 61°
N-Connector female
Mount: 22 mm Tube, Indexing Ring
Width x Length x Height: 260 x 300 (500) x 210 mm
Weight: 1.4 kg
