Input Impedance: 1.5 kΩ || 4 pF
Frequency Range: (9 kHz) 150 kHz – 30 MHz
Voltage range:
HF: < 100 V
AC 50 / 60 Hz: < 10 kV
DC: < 15 kV
Accuracy of Voltage Division: 150 kHz – 30 MHz ±2 dB
Input Impedance of Test Receiver: 50 Ω, SWR ≤ 1.1
Internal Coupling Capacitor: 1.25 nF
Terminals: 4 mm jack
Ground Connection: insulated litz wire, Banana plug
Coax cable: RG 58, 2 m, BNC
Audio Frequency Impedance: 1.25 nF + 1.5 kΩ
Max. Power: 30 W
Weight: 400 g
Dimensions: 440 mm x 23 mm ∅
