Nominal Frequency Range: 300 MHz...7 GH
Usable Frequency Range: 250 MHz ... 8 GHz
Nominal Impedance: 50 Ω
Standing Wave Ratio (SWR) typical: <1.5
Isotropic Gain: typ. 5.8 dBi + / - 1.3 dB
Antenna Factor: 14 ... 43 dB/m
Front to Back Ratio: >25 dB ( >500 MHz)
Cross Polarisation: >20 dB (250 MHz...2.5 GHz)
3 dB Beamwidth typ. (E-Plane): 30°-80°
3 dB Beamwidth typ. (H-Plane): 60°-140°
Max. Input Power: 200 W (<500 MHz)/80 W (5 GHz)/50 W (7 GHz
Connector: N-Connector female
Mount: 22 mm Tube, Indexing Ring
Width × Length × Thickness: 550 x 430 (686) x 50 mm
Weight: 1.1 kg
