Nominal Frequency Range: 800 MHz ... 3 GHz
Usable Frequency Range: 700 MHz ... 5 GHz
Isotropic Gain: typ. 4 ... 7 dBi
Antenna Factor: 24 ... 34 (42) dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio (SWR) typical: 1.5 - 3
Front to Back Ratio: > 15 dB
Cross Polarisation Rejection: typ. 15 dB
3 dB Beamwidth typ. (E-Plane): 50° - 80°
3 dB Beamwidth typ. (H-Plane): 90° - 170°
Max. Input Power: 100 W (intermitt.), 50 W (cont.)
Connector: N-Connectors female
Mount: 22 mm Tube, Indexing Ring
Width × Length × Thickness: 200 × 474 (200) × 200 mm
Weight: 0.8 kg
