SE International Rad-60 Rad-60 Alarming Dosimeter (1 uSv - 9.99 Sv or 0.1 mrem - 999 rem)

Detector

Energy compensated Si-Diode

Button Functions

• change display (dose/dose rate)

• switch ON/OFF

• chirp ON/OFF

• reset integrated dose

• change alarm thresholds

• activate battery test

Measurement Range

Dose: 1 uSv - 9.99 Sv or 0.1 mrem - 999 rem

Energy Response: Hp(10), 60 keV - 3 MeV, better than + or - 25%, up to 6 MeV, better than + or - 35%

Dose Rate: 5 uSv/h - 3 Sv/h or 0.5 mrem/h - 300 rem/h

Dose Rate Linearity: Better than + or - 15% up to 3 Sv/h (300 rem/h)

Calibration: Better than + or -5% (Cs-137, 662 keV at 2 mSv/h), Hp(10)

Audible Alarms

Seven separate alarms, sound level typically better than 85 dBA at 30 cm

• integrated dose

• dose rate

• dose overflow

• dose rate overflow at 3 Sv/h or 300 rem/h

• low battery 1 and 2

• defect

Alarm Thresholds: Six preset values each for integrated dose and dose rate-push button selection

Connectors: Infrared communication via bottom of the dosimeter

Power Requirements: One triple A alkaline cell, typical life is 1800 hours in background

Temperature Range

-20 - + 50° C operational, humidity up to 90% RH, non-condensed

-20 - + 70° C storing

Weight: 80 g (including battery)

Size: 78 x 67 x 22 mm
