Sensata Technologies - Crydom D2450-10 Controller 50A 240VAC DC
Manufacturer: Sensata Technologies - Crydom Model: D2450-10 - Contact
Width: 44.5 mm
Height: 22.6 mm
Length: 57.3 mm
IP Rating: IP00
Output Type: SCR
Unit Weight: 75 g
Contact Form: SPST (1 Form A)
REACH - SVHC: Details
Input Current: 7 mA to 12 mA
Mounting Style: Panel Mount
Termination Style: Screw
Relay Contact Form: 1 Form A (SPST-NO)
Load Current Rating: 50 A
Load Voltage Rating: 24 VAC to 280 VAC
Control Voltage Range: 3 VDC to 32 VDC
Pd - Power Dissipation: 500 mW
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
