Sensata Technologies - Crydom DC60S7-B Isolated PM IP00 SSR 60VDC 7A, 3.5-32VDC,NC
Manufacturer: Sensata Technologies - Crydom Model: DC60S7-B - Contact
Width: 44.5 mm
Height: 22.6 mm
Length: 57.3 mm
IP Rating: IP00
Output Type: Bi-Polar Transistor
Unit Weight: 86.500 g
Contact Form: SPST (1 Form B)
REACH - SVHC: Details
Input Current: 2.2 mA to 25 mA
Mounting Style: Panel Mount
Termination Style: Screw
Relay Contact Form: 1 Form B (SPST-NC)
Load Current Rating: 7 A
Load Voltage Rating: 3 VDC to 48 VDC
Control Voltage Range: 3.5 VDC to 32 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 30 C
Input to Output Isolation Method: Optocoupler
