Switch: without
Nominal width: DN 10
Process connection: female thread G 3/8 (further process connections available on request)
Display range: 0.5 - 6.0 l/min for details see table "Ranges"
Qmax.: 10 l/min
Tolerance: ±5 % of the full scale value
Pressure resistance: PN 200 bar optionally PN 500 bar
Media temperature: -20..+70 °C
Ambient temperature: -20..+70 °C
Media: water, oils (gases and aggressive media available on request)
Electrical data: none
Materials medium-contact
Brass construction: CW614N nickelled, CW614N, 1.4310, hard ferrite, NBR
Non-medium contact materials: PC, acrylic
Weight: see table "Dimensions and weights"
Installation location
Standard: horizontal inwards flow from the left; other installation positions are possible; the installation position affects the display range.
