Version: Standard
Measuring range: ±500.0 hPa
Resolution: 0.1 hPa
Overpressure limit: ±1500hPa
Accuracy:
±0.15 %FSS (*) ± 1 digit typ. @ 25 °C
±1.5 %FSS ± 1 digit max.
Auto power off:;
Yes, user configurable
Automatically disabled if external power is connected
Battery autonomy: > 150 h typ. continuous operation
Channels:
1 differential
2 x universal barbed pressure ports (+/-) for 4 and 6 mm inner diameter hose
Interchangeable G 1/8 thread connections
Clock: User settable RTC; Max. drift 1 min/month @ 25 °C
Compatible media: Air and non-aggressive dry gases
Dimensions: 170 x 78 x 38 mm
Housing material: ABS, TPE (side protection), Polyester (front panel)
Logging interval: 1, 5, 10, 15, 30 s / 1, 2, 5, 10, 15, 20, 30 min / 1 hour (only PRO 215)
Logging type Automatic with manual or scheduled start/stop (only PRO 215); Long-term drift ±1 %FSS/year max.
Measurement rate: 4 meas/s
Operating conditions: -5…50 °C / 0…85 %RH non-condensing
PC connection: USB C ;Mass Storage Device (only PRO 215)
Power consumption: 20 mA typ.
Power supply: 4 x AA alkaline batteries; External 5 Vdc via USB C (power adapter or PC USB port)
Protection degree: IP 67 (except pressure ports and Tc K input); IK 04
Storage capacity:
Up to 1 million data sets, file system based
Each data set includes date/time stamp and measurements of all channels
Data are stored in CVS files
(only PRO 215)
Storage temperature: -25…65 °C (without batteries)
Temperature drift (ref. 25 °C): ±0.002 %FSS/K typ.
User interface: Multilingual (de, en, it, fr, es)
Weight: 340 g approx.
Display: 140 x 160 dot matrix backlit LCD / Visible area 42 x 50 mm
Multiple choice of measurement screens:
Large digit single value
Multi-row
Statistical info (Min/Avg/Max)
Chart view
Alarm function: sound & light
Current supply: 4 batteries (Mignon AA/LR6) or via USB socket
Measuring input: Differential pressure, air and non-aggressive dry gases
Output: USB jack type C
Pressure connection: 2x universal pressure port for tube 6x1 mm (4 mm inner-Ø) or 8x1 mm (6 mm inner-Ø)
Protection type: IP67 (except sensor input)
Scope of delivery: Device in carton box, incl batteries, 2 hoses, testprotocol, Quickstart
