AC Voltage:
Range: 400mV/4V/40V/400V/750V
Resolution: 0.1mV/1mV/10mV/100mV/1V
Accuracy: ±(1.0%rdg+5dgt)
DC Voltage:
Range: 400mV/4V/40V/400V/1000V
Resolution: 0.1mV/1mV/10mV/100mV/1V
Accuracy: ±(0.5%rdg+3dgt)
Resistance:
Range: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
Resolution: 0.1Ω/1Ω/10Ω/100Ω/1kΩ/10kΩ
Accuracy: ±(1.2%rdg+3dgt)/±(2.0%rdg+4dgt)
Continuity Test:
Range: 400Ω
Audible threshold: Less than 25Ω
SPECIFICATIONS:
Frequency detection: Amplifier Probe: 1Hz~12kHz / Tone Generator: 1kHz ±15%
Over protection: Tone Generator: 80V DC
Alternating tone: Fast and Slow
Connection: Tone Generator : RJ11 connector / alligator clip x 2
Sensitivity control
Receiver distance: <50cm
Operating temperature & humidity: 0°C ~ 40°C, 80% Max.
Temperature & humidity:
Operating: 0°C~40°C ≤80% R.H.
Storage: -10°C~50°C ≤80% R.H.
Dimensions:
Amplifier Probe: 230(L) x 56(W) x 27(D)mm
Tone Generator/DMM: 183(L) x 82 (W) x 44(D)mm
Weight (battery included):
Amplifier Probe: 125g
Tone Generator/DMM: 305g
Power source:
Amplifier Probe: 9V(6F22) × 1
Tone Generator: 9V(6F22) × 1
DMM: 1.5V(AAA) x 2
Safety standard: EN 61010-1 CAT Ⅲ 600V, EN 61326-1 EN 55011, EN 61000-4-2, EN 61000-4-3
