Laser Source Module:
Wavelength (±20nm): 1310/1550
Output Power: ≥ -7dBm
Spectral Width: ≤ 5nm
Emitter Type: FP-LD
Stability: ±0.05 dB/15min
: ±0.10dB/8hr@1310/1550nm; ±0.15dB/8hr@850/1300nm
MOD Frequencies: 270, 1K, 2K Hz
Connector Type: FC/PC (Interchangeable ST, SC)
Optical Power Meter Module:
Detector Type: InGaAs
Measurement Range: -70 ~ +10dBm (1)
Accuracy: ± 5% ± 0.01nW (±0.5dB@850nm)
Resolution: 0.01dB
Calibrated Wavelength(2): 850, 1300, 1310,1490, 1550, 1625nm
General Specifications:
Power Supply: 9V Alkaline battery / optional 9V AC adapter
Battery Life: OPM mode≥40 hours; OPM+SLS mode≥20 hours
Operating Temperature: -20℃ to 50℃
Storage Temperature: -40℃ to 70℃
Relative Humidity: 0 to 95% (Non-condensing)
Weight: 300g
Dimension (H×W×T): 145×75×25mm
Note: (1) At 850nm, the lower limit of measurement range is -60 dBm;
(2) Other wavelengths are open for customization.
* Specifications subject to change without notice
Ordering information
Standard Configuration:
Instrument, 9V alkaline battery, Rubber boot, Warranty card, CE certificate, Certificate of Calibration, User's manual
