Shinzawa SV-65DT Drill And Tap Center Machine (650x430x340mm)

TRAVEL

X axis (mm): 650

Y axis (mm): 430

Z axis (mm): 340

Spindle nose to table surface (mm): 150 ~ 490

WORK TABLE

Table size (mm): 750 x 400

T- slot (W x No. x P) (mm): 14 x 3 x 125

Max. loading (average) (kg): 250

SPINDLE

Max. spindle speed (rpm): 10000 (Fanuc), 12000 (Mitsubishi)

Drive type: Direct drive

Motor power output (kW): 3.7 / 5.5

Spindle taper: BT - 30

FEEDRATE

Rapid traverse speed on X/Y/Z axes (M/min): 48 / 48 / 48 (Mitsubishi); 36 / 36 / 36 (Fanuc)

Max. cutting feedrate (M/min): 12

Servo motor of X/Y/Z  (kW): 1.5 / 1.5 / 2.0  (Mitsubishi); 1.2  /  1.2  /  1.8 (Fanuc)

AUTOMATIC TOOL CHANGER ():

Tool capacity (pcs): 16T (21 T)

ATC type: Clam type

Max. tool diameter (w/ adjacent tool) (mm): Ø100

Max. tool length (mm): 200

Max. tool weight (kg): 3

OTHER

Total require power (kva): 15

Machine dimension (L x W x H) (mm): 1900 x 2575 x 2410

Machine weight (kg): 3000
