Basic Accuracy
Resistance: 0.5%
Capacitance: 1%
Inductance: 1%
Measurement Ranges
Resistance R: 0.1 Ω to 10 Ω
Capacitance C: 2 pF to 5mF
Inductance L: 0.5 uH to 999 mH
Technical Specifications
Test Frequency: 1 kHz, 10 kHz, 100Hz
Test Signal Level: 0.45 +/- 5% Vrms Sine wave
Source Impedance: 62.5Ω/1K Ω/15kΩ +/- 1%
Physical Specification
Size: 14.8 x 2.0 x1.5 cm (5.8 x 0.76 x 0.57 in)
Weight: 29 grams (0.063 lb)
Display: 0.91-inch, 128x32 OLED display
Battery Type: 3.7V LiPO; Rechargeable 220 mAh
Battery Life: 40 hours (2-hour charging cycle)
Charging Source: USB power adapter (output voltage DC 5V)
Storage Compliance: -20 ° to 60 °, 0% to 80% RH
Operating Temperature: 0 °C to 50 °C
