Application: Outdoor
Light source: Infrared light (905 nm, ± 10 nm)
Laser class: 1 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 85° (working range with 8 scan layers, 25° working range expansion with 4 scan layers (total 110°)) / Vertical 4.2° ... 6.4° (± 0.2°)
Scanning frequency: 12.5 Hz ... 50 Hz
Angular resolution: 0.125° / 0.25° / 0.5°
Working range: 0.5 m ... 320 m
Scanning range: At 10% remission 30 m / At 90% remission 150 m
Connection type: Circular plug-in connector
Supply voltage: 9 V ... 27 V
Power consumption: 8 W
Housing color: Gray (RAL 7032), black (RAL 9005)
Protection class: III
Enclosure rating: IP69K
Weight: 1 kg
Dimensions (L x W x H): 94 mm x 165 mm x 88 mm
Interface: Ethernet, TCP/IP
