Application: Indoor
Light source: Light source Infrared (905 nm)
Laser class: 1, complies with 21 CFR 1040.10 and 1040.11 except for the conformance according to “Laser Notice No. 50” from June 24, 2007 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 270°
Scanning frequency: 25 Hz
Angular resolution: 0.5° / 1°
Working range: 0 m ... 10 m
Scanning range: At 10% remission 4.5 m
Connection type: 1 x system plug with screw terminal block (accessory)
Supply voltage: 16.8 V DC ... 30 V DC
Power consumption: 8 W
Housing color: Black (RAL 9005)
Protection class: II (VDE 0106, EN50178)
Enclosure rating: IP65 (EN 60529, Section 14.2.5)
Weight: 1.2 kg without connecting to cables
Dimensions (L x W x H): 105 mm x 102 mm x 152 mm
Mounting method: Mounting height 2 m ... 5 m (typ. 2.5 m ... 3.5 m)
Response time: 4 layers, typ. 20 ms / 1 layer, typ. 80 ms
Ethernet: ✔, TCP/IP, UDP/IP
Digital inputs/outputs: I/O (8 (Multiport))
