Measurement principle: HDDM+
Application: Indoor
Light source: Infrared (850 nm)
Laser class: 1 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 270°
Scanning frequency: 15 Hz
Angular resolution: 1°
Working range: 0.05 m ... 4 m
Scanning range: At 10% remission : 2 m
Connection type: 1 x M12 12-pin male connector (0.8 m)
Supply voltage: 9 V DC ... 28 V DC
Power consumption: Typ. 4 W, 16 W with 4 max. loaded digital outputs
Output current: ≤ 100 mA
Housing color: Light blue (RAL 5012)
Weight: 150 g, without connecting cables
Dimensions (L x W x H): 60 mm x 60 mm x 79 mm
