| Model | SDS1302CFL | |||
| Bandwidth | 300MHz | |||
| Channels | 2/4CH+1EXT | |||
| Real time sampling rate | 1GSa/s(each channel), 2GSa/s(half channel) | |||
| Equivalent sampling rate | 50GSa/s | |||
| Memory depth | 12K(each channel), 24k(half channel) | |||
| Rise time | < 5ns | < 3.5ns | < 1.7ns | < 1.2ns |
| Input impedance | 1MΩ‖13pF | 1MΩ‖13pF, 50Ω | ||
| Time base range | 1.0ns/div-50s/div | |||
| Scan: 100ms-50s/div | ||||
| Vertical sensitivity | 2mV - 5V/div | |||
| Vertical resolution | 8bit | |||
| Trigger source | CH1, CH2, CH3, CH4, Ext, Ext/5, AC Line | |||
| Trigger types | Edge, Pulse, Video, Slope, Alternative | |||
| Math Operation |
+, -, ×, ÷, FFT |
|||
| Digital filter | High pass, Low pass, Band pass, Band Stop | |||
| Max input voltage | ±400V(DC+ACPk-Pk), CAT I, CAT II | |||
| Internal storage |
2/4 groups of reference waveform, 20 groups of settings, 20 groups of waveforms |
|||
|
External storage |
Bitmap save, CSV save, Waveform save, Setting save |
|||
|
Language |
English, French, German, Russian, Spanish, Simplified Chinese, Traditional Chinese, Portuguese, Japanese, Korean, Italian, Arabic |
|||
|
Interface |
Double USB Host, USB Device, LAN, Pass/Fail out |
|||
|
Display |
7’’color TFT-LCD |
|||
|
Power |
AC 100-240V, 45Hz-440Hz, 50VA Max |
|||
|
PC software |
Can through the computer remote control oscilloscope, extraction waveform analysis data |
|||
|
Remark |
With original source seamless connection, form signal collection, produce integration system |
|||
|
Detailed performance parameters and technical index please refer to《SDS1000CFL Series Datasheet》 |
||||
Optional Accessories:
1. BNC Coaxial cable
2. USB-GPIB
3. EasyDsoLib Software setups (free)
4. Oscilloscope portable bag
