Bandwidth: 300MHz
Sampling rate (Max.): 2GSa/s
Channels: 4+EXT
Memory depth (Max.): 140Mpts (Single-Channel), 70Mpts (Dual-Channel)
Waveform capture rate (Max.): 140.000wfm/s (normal mode), 500.000wfm/s (sequence mode)
Trigger type: Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video
Serial Trigger: IIC, SPI, UART/RS232, CAN, LIN
Decoder type (Optional): IIC, SPI, UART/RS232, CAN, LIN
16 digital channels (MSO Option): Maximum waveform capture rate up to 500 MSa/s, Record length up to 14 Mpts/CH
Waveform generator (Optional): Single channel, Max. frequency up to 25MHz, 125MSa/s sampling rate, 16Kpts wave length
I/O: USB Host, USB Device, LAN, Pass/Fail, Trigger Out
Probe (Std): SP2030A 300MHz; 1 pcs for each channel
Display: 8 inch TFT LCD (800x480)
