Bandwidth: 200MHz
Channels: 2CH
Memory depth: 32kpts
Rise time: ≤1.7ns
Real time sample rate: 500MSa/s
Equivalent sample rate: 50GSa/s
Time base range: 2.5ns/DIV~50s/DIV
Vertical sensitivity: 2mv/div~100v/div
Vertical resolution: 8 bit
Modulation type: Edge, Pulse, Video, Slope, Alternative
Data recorder: 7 Mpts
Trend plot: 800 Kpts
Triggering frequency counter: 6 digits
Interface: USB Device, USB Host
Multimeter specification
Maximum resolution: 6000
DC Voltage: 60mV-1000V; ±1%±15digit
AC Voltage: 60mV-750V; ±1.5%±15 digit
DC Current: 60mA-10A; ±5%±5 digit
AC Current: 60mA-10A; ±5%±5 digit
Capacitance: 40nF; ±4%±10digit
400nF-400μF; ±5%±5digit
Resistance: 600Ω-6MΩ; ±1%±5digit
60MΩ; ±4%±5digit
Continuity: <50Ω
Diode: 0-2V
Trend Plot: 1.2Mpts
Other specification
Display: 5.7 inch color TFT-LCD, 320*234
Power supply: Charging/Battery
Net weight: 1.5kg
Dimension: 163.2*259.5*53.3mm
Standard accessories
A 9V, 4A, power adapter
Two 1X/10X oscilloscope probes
Two test leads for multimeter
Probe calibration accessory
A USB data transmitting cable
Quick start
Certificate of calibration
Optional probe
100MHz high-voltage safety probe CAT II 1000V,CAT III 600V
200MHz high-voltage safety probe CAT II 1000V,CAT III 600V
