Width: 48.3 mm (1.902 in)
Height: 25 mm (0.984 in)
Length: 101.6 mm (4 in)
Industry: Medical, Industrial
Approvals: EN60601-1, IEC60601-1 UL60601-1, EN62368-1, IEC62368-1, UL62368-1
Compliance: EN/IEC/UL60601-1, EN/IEC/UL62368-1
Unit Weight: 220 g
Output Power: 30 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: PCB
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 2.5 A
Output Voltage-Channel 1: 12 VDC
Operating Temperature Range: - 25 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 25 C
