Width: 50.8 mm
Height: 31.8 mm
Length: 101.6 mm
Industry: Medical
Approvals: ANSi/AAMI ES60601-1, CAN/CSA-C22.1 No. 60601-1, DEMKO EN60601-1, IEC60601-1
Compliance: ANSi/AAMI ES60601-1, CAN/CSA-C22.1 No. 60601-1, DEMKO EN60601-1, IEC 60601-1
Efficiency: 93 %
Unit Weight: 225 g
Output Power: 120 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 8 A
Output Voltage-Channel 1: 15 VDC
Operating Temperature Range: - 10 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 10 C
