SMAC APD-200V D-Frame Single Point Press
Manufacturer: SMAC Model: APD-200V Guarantee: 12 Month - Request a Quotation
- Contact
Capacity (Ton): 200
Rated tonnage piont (mm): 6
Stroke (mm): 200
Die height (mm): 460
Stroke per minute (s.p.m): 20-50
Slide adjustment (mm): 110
Slide area (mm): 850x630x90
Bolster area (mm): 1140x820x160
Main motor (kw.p): 18
Air pressure (kg/cm2): 6
Presses dimension (mm): 1750x2500x3900
Presses weight (Ton): 25.3
Die cushion capacity (Ton): 14
Stroke (mm): 100
Die cushion effective area (mm2): 710x480
