Max. Drilling capacity (mm): 32/40
Distance Spindle axis to column generating line (mm): 320-820
Diameter of column (mm): 200
Spindle taper (mm): MT4
Spindle travel (mm): 210
Spindel speeds range (mm): 75-1220
Spindle speeds series: 6
Range of Spindle feeds (mm/r): 0.1-0.25
Spindle feed: 3
Max. Distance nose to working surface of base (mm): 320-900
Dimension of worktable (mm): 400x400x350
Dimension of base (mm): 1370x700x160
Overall Size (cm): 140x72x188
Power of main motor (kW): 1.5
G.W/N.W: 1425/1200
Packing dimension (cm): 155x77x210
Standard Accessories: Box shape worktable, Taper sleeve, Tool releasing Wrench, Drift, Eyelet bolts
Optional Accessories: Quick instead chuck, Tapping chuck, Grease gun
