Worktable
Dimensions (mm): 1300x610
T-slot Sizes (mmxN): 18x5
Max Load (kg): 1000
Machine range
X Axis Travel (mm): 1100
Y Axis Travel (mm): 610
Z Axis Travel (mm): 650
Max distance from Spindle Nose to Worktable (mm): 800
Min distance from Spindle Nose to Worktable (mm): 150
Spindle
Taper: BT40
Speed (rpm): 8000
Main Motor Torque (Nm): 52.5
Main Motor Power (kW): 11/15
Feed
X/Y/Z Axis Rapid Traverse (m/min): 32/32/30
Feed Speed (m/min): 20
Tool Magazine
Type: mechanical arm
Stations (number): 24
Changing Time (s): 2.5
Positioning Accuracy
JISB6300 (mm): ±0.005/300
JB/T8771.4 (mm): 0.016/0.012/0.012
Repositioning Accuracy
JISB6300 (mm): ±0.003
JB/T8771.4 (mm): 0.010/0.008/0.008
Gerneral Power Capacity (KVA): 25
Air-supply Pressura (Mpa): 0.5-0.7
Dimensions & Weight
Footprint (mm): 3000x2565
Height (mm): 2944
Weight (kg): 8000
CNC System: FANUC
Standard Accessories: Three-axis Ball Screw, linear guide rail X axis, linear guide rail Y axis, linear guide rail Z axis, Stainless-steel Guideway Protection, Full Enclosue, Water Tank Chip Conveyors, Lubricating System, Pneumatic System, Air Gun, Heat Exchanger, FANUC CNC System, SIEMENS CNC System, Ethenet, BT40 24T Mechanical Arm Tool Magazine, BT40 8,000RPM Spindle
Optional Accessories: Chain-type Chip Conveyors, Scraper-type Chip Conveyors, Magnetic Chip Conveyors, FIYANG CNC System, Thru-Spindle Coolant 20BAR, Renishaw NC4 Tool Detection, Renishaw TS27R Tool Detection, Marpross ML75P Tool Detection, Marpross TS30 Tool Detection, Renishaw OMP60 Workpiece Detection, Marpross E83Wa Workpiece Detection, Linear Scale, Hydraulic Monitor, Rotary Table, Air Conditioner, CE Standard, BT40 20T Umbrella Tool Magazine, BT40 10,000RPM Spindle, BT50 6,000RPM Spindle
