Worktable
Dimensions (mm): 2200x800
T-slot Sizes (mmxN): 22x5
Max Load (kg): 3000
Machine range
X Axis Travel (mm): 2100
Y Axis Travel (mm): 800
Z Axis Travel (mm): 800
Max distance from Spindle Nose to Worktable (mm): 1000
Min distance from Spindle Nose to Worktable (mm): 200
Spindle
Taper: BT50
Speed (rpm): 6000
Main Motor Torque (Nm): 380
Main Motor Power (kW): 15/18.5
Feed
X/Y/Z Axis Rapid Traverse (m/min): 18/18/18
Feed Speed (m/min): 10
Tool Magazine
Type: mechanical arm
Stations (number): 20
Changing Time (s): 3.5
Positioning Accuracy
JISB6300 (mm): ±0.008/300
JB/T8771.4 (mm): 0.022/0.012/0.012
Repositioning Accuracy
JISB6300 (mm): ±0.003
JB/T8771.4 (mm): 0.013/0.008/0.008
Gerneral Power Capacity (KVA): 37
Air-supply Pressura (Mpa): 0.5-0.7
Dimensions & Weight
Footprint (mm): 6705x3500
Height (mm): 3910
Weight (kg): 17500
CNC System: FANUC
Standard Accessories: Three-axis Ball Screw, 4linear guide rail X axis, linear guide rail Y axis, box guideway Z axis, Stainless-steel Guideway Protection, Full Enclosue, Chain-type Chip Conveyors, Lubricating System, Pneumatic System, Air Gun, Heat Exchanger, FANUC CNC System, SIEMENS CNC System, Reduction Gearbox, Ethenet, BT50 20T Mechanical Arm Tool Magazine, BT50 6,000RPM Spindle
Optional Accessories: Scraper-type Chip Conveyors, Magnetic Chip Conveyors, FIYANG CNC System, Thru-Spindle Coolant 20BAR, Renishaw NC4 Tool Detection, Renishaw TS27R Tool Detection, Marpross ML75P Tool Detection, Marpross TS30 Tool Detection, Renishaw OMP60 Workpiece Detection, Marpross E83Wa Workpiece Detection, Linear Scale, Hydraulic Monitor, Rotary Table, Air Conditioner, CE Standard, BT50 16T Umbrella Tool Magazine, BT50 32T Chain Tool Magazine
