Max drilling diameter and tapping diameter: Φ25/M20
Max travel of spindle: 150
Max distance from spindle to generating line of column: 300
Max distance between spindle end to the worktable surface: 800
Max distance from spindle end to the surface of base worktable: 1225
Max travel of spindle box: 270
Max travel of worktable and bracket (Mannual/Mechanical): 550
Spindle taper bore: 4
Spindle speed steps: 12
Spindle speed range: 78-2500
Dimension of worktable: mx 190^2
Effective working area of worktable: 365x415
Power of motor: 1/1.3/1.7
Machine dimension: 835x510x1730
Packing dimension: 940x570x2120
Net weight/Gross weight: 430/475
Accessories: Shalf sleeve for taper shank tool, Key type drill chuck, Connecting bar for drill chuck, Wedge for taper shank tool, Double open end spanner.
