Length: 250mm
Mechanical
Typical Life Cycle: > 100 x 10^6 cycles, > 25 x 10^6 m
Stroke: > 50 - 1250 mm
Linearity up to: ± 0.05%
High Resolution: Infinite
Repeatability: ± 0.01 mm
Max. operating speed: 10 m/s
Environmental
Housing: Anodized Aluminium Housing
Operating Temperature: -30... +100° C
Storage Temperature: -50...+120° C
Electrical
Current resistance: ≤ 10mA
Current wiper: ≤ 1 mA
Operating Force: ≤ 2N
Power Consumption: 3W - 10W
Output Smoothness: <± 0.1% against input voltage
Input Voltage: 60 V max
Insulation Voltage: 500V - 1min Residue < 5 µ A
