Temperature range (*1): -10℃ to +80℃
Ambient temperature range: +5℃ to +35℃
Control accuracy (*2): ±0.5℃, Heater PID control
Compressor output, Refrigerant: 400W, R404A
Cooling capacity (at 50Hz)(*3): approx. 0.7kW
Heater output: 1.8kW
Temperature setting display: Digital system (setting/display switching system)
Safety device/function: Short/Over current breaker, Alarm and warning for compressor, High and Low temperature, Alarm and warning for pump motor, Temperature sensor abnormality diagnosis circuit, Alarm for replenishing liquid, Low-water cut off, Phase-reversal relay
Other Functions: Temperature check monitor, Remote temperature setting, Temperature monitor signal output, Safety device actuation signal output, External temperature sensor connection (*4)
Water bath capacity (*5): approx. 26L (water level 80%)
Applicable pump unit: P-320, P-420, P-52
External dimensions (Pump unit not included): 407×565×766 mm
Weight (Pump unit not included): approx. 66kg
Power Supply (Pump unit not included): Three-phase AC200V/15A 50/60Hz, MAX17A: Need a step-down transformer
Operation current (Pump unit not included): 8A
Standard Accessory: Power code, Drain hose x 1, Connector for signal x 1
Catalog
(*1)When setting below +7ºC, please be sure to use antifreeze (Please ask us for details).
(*2)Performance may not be maintained due to the heating medium, environmental temperature, heat load, circulation pipe distance, etc.
(*3)Capacity when using tap water and the circulating fluid temperature at 10 ℃ . The capacity varies with the pump unit mounted.The capacity decreases when the ambient temperature is above +30℃
(*4)External temperature sensor (φ4×250mm) is available as an option.
(*5)Due to the structure not being sealed, the circulation liquid may evaporate and reduce depending on the set temperature and heating medium type.
