Temperature range/accuracy: 5℃ above RT to 50℃, ±0.2℃ (*1)
Heating method: Air Jacket type (6 Heaters)
Gas control range: CO2 : Atmospheric concentration to 20% (Set in 0.1%) (*2) O2 : 1% to 20% (Set in 0.1%) (*3)
Ambient temp. range: +15℃ to +35℃
Humidification method: Natural evaporation by the Humidity pan
Inner Dimensions(W×D×H)/Chamber volume: Chamber: 354 × 425 × 418 mm, Approx. 53 L
Example of Capacity: Per shelf: Petri Dish φ35 mm ×49 , Well plate ×6 , 14 × 25 cm2 of TC flask
Other functions: Connection holes (inner dia. φ30 mm)× 2 pcs, Outlet for external supply (Max. 3 A), RS-232C terminal
Gas connection port: Barbed nozzle φ9 mm (Replaceable: 1/4Rc)
Dimensions(W×D×H)/Weight: 476 × 578 × 638 mm, Approx. 51 kg
Standard accessories: Shelf (Antibacterial treatment )× 3 pcs(*4),Shelf support × 6 pcs,Humidity pan ×1 pc, Gas supply tube (10 m)×1 pc, Hose band× 4 pcs
Power supply: AC100V/3.5A/Max.6.5A (Need a step-down transformer)
(*1)The value at the ambient temperature 25℃ and operation temperature 37℃/CO2 5%.
(*2)Measured by Infrared type CO2 sensor.
(*3)Measured by Zirconia type oxygen sensor.
(*4)Up to Six shelves can be stored.
● "Multi-gas" is a specification that controls CO2 and O2 Concentration by connecting CO2 Gas and N2 Gas or O2 Gas.
