Temperature range (*2)(Thermominder): 5℃ above RT to +70℃ (Preset/Current temp. displayed simultaneously in the SDN/EXN switch. Switchable Preset/Current temp display in SM.)
Temp. control accuracy (*3)(Thermominder): ±0.1℃
Temperature memory(Thermominder): -
Timer (*4)(Thermominder): -
Other functions(Thermominder): Buzzer notification when preset temp. is reached,Automatic tuning
Heater(Thermominder): 500 W
Safe devices/protections(Thermominder): Circuit protector, Fuse, Dry-heating protection with float, Heater protection cover (SM-05N), Sensor error, Short circuit, High/Low temp. Sample protection,Water level alarm, Non-volatile memory error, Automatic tuning error, Alarm setting error, Switchable Automatic/Manual recovery when power failure
Power supply(Thermominder): AC 100 V/5.5 A
Standard accessories(Thermominder): Microtube Floater × 1 pc, Plastic Water bath C-type × 1 pc (*5)
Shaking method(Personal): Reciprocal shaking, Shaking speed: 20 to 160 r/min (displayed digitally), Shaking width: 10 to 40 mm (Stepless variable, Default 30 mm)
Platform dimensions(Personal): 220 × 310 mm
Other functions(Personal): Elapsed time indicator (0.1 to 999.9 h, with Automatic reset) × 1 , Service outlet for Thermominder ×1
Bath inside dim.(W×D×H)/volume(Personal): 235 × 430 × 140 mm, Approx. 11 L (80% Water level) (*6)
Power supply(Personal): AC100V/0.5A /Max.6A with SM-05N (Need a step-down transformer)
Standard accessories(Personal): Spring net Shaking Platform × 1 pc, Clamp Spacer × 1 pc
Dimensions (W×D×H)/weight: 300 × 527 × 420 mm, Approx. 19.4 kg
Catalog
(*1)Can be combined with SJ-07N and SX-10N.
(*2)Max. temp. may not be reached when the optional Hood is not used or depending on the usage conditions.
(*3)The value under the conditions of RT (25℃), AC 100V/50 Hz, 80% Water level, Preset temp. 37℃, and No heat load. Only for EXN Measured value.
(*4)Each setting range is 1 min to 99 h 59 min.
(*5)This also serves as a packing box whereas it is not used together with
the Personal-11 Set.
(*6)The proper volume is 7 L to 9 L when shaking with the capacity (max. number) such as Centrifuge tubes and max. 500 mL of Erelnmeyer flasks at 120 to 160 r/min.
