Resolution (H x V Pixels): 5496 x 3672 (full resolution) 5472 x 3648 (default resolution)
Resolution: 20 MP
Sensor Type: Sony IMX183CLK-J / Progressive scan CMOS / Rolling shutter
Sensor Format: 1 inch
Effective Sensor Diagonal: 15.86 mm
Pixel Size (H x V): 2.40 x 2.40 μm
Frame Rate (at Default Settings): 17 fps
Mono / Color: Mono
Image Data Interface: USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈2.9 W (typical) @ 5 VDC
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line / 2 general purpose I/O (GPIO) lines
Lens Mount: C-mount
Size (L x W x H): 29.3 x 29 x 29 mm (without lens mount or connectors) 48.2 x 29 x 29 mm (with lens mount and connectors
Weight: <80 g
Conformity: CE (includes RoHS), EAC, UL Listed, FCC, GenICam 2.x (including PFNC 2.x and SFNC 2.x), IP30, USB3 Vision, REACH, KC
