TECHNICAL DATA:
Output voltage: 0 … 10kV
Output current: 150mA
Test voltage: 0 … −10kV
Insulation resistance test: 0…650MΩ
Maximum permitted capacity of the test object: 10 uF
Pinpointing: 0 -10 kV DC, pulsed selectable ; 0.5:1 / 1:2 / 1.5:3.5
Power supply (rated voltage): AC 90V…240V,50/60Hz
Battery: Built-in battery (615Wh)
Endurance (battery powered): 6h
Power consumption: max. 800 VA
Display: 8000 x 480 LCD, 1000cd/m²
Operating temperature: -20℃...+55℃
Storage temperature: -40℃...+65℃
Dimensions (W x H x D): 500*457*305mm
Weight: 18.5KG
Protection rating: IP54
