Gain: 2.7 dBi, 3.8 dBi, 5 dBi, 5 dBi, 5 dBi, 3.5 dBi, 3.8 dBi, 6.4 dBi, 5.5 dBi
Style: T-Pad Flex
Width: 50.4 mm
Height: 0.2 mm
Length: 120.4 mm
Impedance: 50 Ohms
Cable Type: 150 mm RF1.37
Technology: UWB
Application: Ultra Wide-band Application
Unit Weight: 6.380 g
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1400 MHz, 1575 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2300 MHz, 2400 MHz, 2600 MHz, 3500 MHz, 5000 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 6 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
