Gain: 0.6 dBi, 2.7 dBi, 2.7 dBi, 4.4 dBi, 2.2 dBi, 1.2 dBi, 4.6 dBi, 5.4 dBi
Style: Straight with Base
Width: 96.61 mm
Height: 61.45 mm
Length: 165.45 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: RG174
Application: Cellular Application, Satellite Tracking/Navigation, Wireless Application
Unit Weight: 230 g
Cable Length: 300 mm
Polarization: LHCP, RHCP
Mounting Style: Direct / Permanent Mount
Number of Bands: 5 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2400 MHz, 2328 MHz, 1561.098 MHz, 1575.42 MHz,
Mechanical Style: Whip
Maximum Frequency: 2.5 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: FAKRA A, FAKRA C, FAKRA D, FAKRA K
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS, IRNSS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, GPRS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
