Gain: 0.21 dBi, 0.36 dBi, 3.07 dBi, 3.1 dBi, 3.68 dBi, 4.51 dBi
Style: I-Bar Flex
Width: 21 mm
Height: 0.2 mm
Length: 96 mm
Impedance: 50 Ohms
Cable Type: 150 mm RG1.37
Technology: NB-IoT / CAT M1
Application: Automotive, Medical, Smart City, Smart Meter
Unit Weight: 2.442 g
Cable Length: 150 mm
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Number of Bands: 6 Band
Center Frequency: 700 MHz, 1.7 GHz, 1.9 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 3 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF1
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM
