Gain: - 0.68 dBi, - 2.14 dBi, 0.15 dBi, - 0.74 dBi, - 0.59 dBi, 1.37 dBi, 0.93 dBi, 0.73 dBi, 1.51 dBi, 1.73 dBi
Style: Blade Tilt / Swivel
Width: 23.9 mm
Height: 13 mm
Length: 172 mm
Impedance: 50 Ohms
Application: Gateways, Routers, Smart Metering, Vending Machinges, Industrial IoT, Smart Home, Connected Enterprise
Unit Weight: 25.012 g
Polarization: Linear
Power Rating: 2 W
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 10 Band
Center Frequency: 657 MHz, 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1474 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz, 3400 MHz, 3600 MHz, 4000 MHz, 5200 MHz, 5800 MHz
Mechanical Style: Whip
Maximum Frequency: 6 GHz
Minimum Frequency: 600 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi, WiFi 6E
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA, HSPA, EDGE, GPRS
