Gain: 1.18 dBi
VSWR: 2:1
Style: I-Bar
Width: 30 mm
Height: 7.7 mm
Length: 105 mm
IP Rating: IP65
Impedance: 50 Ohms
Cable Type: 1 M RG174
Technology: WiFi
Application: First Tier Automotive Application, Aftermarket, Telematics
Unit Weight: 50 g
Cable Length: 1 m
For Use With: WiFi, WLAN
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Module
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
