Characterized frequency range: 0.1 Hz to 100 MHz
3 dB bandwidth: 1 Hz to 30 MHz (measured in a 50 + 50 Ohm loop)
Transfer impedance into 50 Ω load: -26 dBΩ; 0.05 V/A
Transfer impedance into high Z: 0.1 V/A
Probe port impedance: 50 Ω
Droop rate: 0.2 %/ms
Rise time: < 10 ns
Max. RMS AC current: 100A
Max. pulse current: 5000A
Current time product: 0.7 Ampere seconds
Max. core temperature: 80 °C
Aperture diameter: 46 mm
Outside diameter: 124 mm
Height: 37 mm
Weight: 1050 g
Connector type: N female; comes supplied with a coaxial adapter to BNC-female
